Zallys ML1 is the lightest and easiest to handle electric bed mover for hospital beds. Thanks to its compact size and light weight, it can easily fit into elevators and the narrowest hallways.
The ML1 bed mover is equipped with adjustable clamps, electronically controlled by the operator, which fit most of hospital beds. ML1 bed mover can easily be driven with a wired control unit, reversible and portable, which can be moved from its housing, allowing the operator to use it from the other side of the bed. It is equipped with several safety systems such as emergency button and manual release of clamps. Interchangeable battery packs allow 24/7 operation to cover several work shifts.
All Zallys vehicles are produced with high quality materials and are CE certified according to the latest European normative.
- For moving beds of a total weight up to 500 kg
- Compact, it guarantees access to elevators while clamped to the bed (increases the total length by only 30 cm)
- Interchangeable battery pack to guarantee 24/7 operation
- Button for 5-speed adjustment
- Easy-to-use and lowest manual effort
- Safe and silent
| Specifications | Units | Details |
| Nominal power | V / W | 24 / 300 |
| Battery (Standard) | Ah | AGM 16/22A |
| Max. speed | km/h | 4,0 |
| Max.towing capacity on flat ground (without ballasts) | kg | ~ 500 |
| Max.towing capacity on flat ground (with ballasts) | kg | ~ 1000 |
| Max towing force at hook | N | ~ 600 |
| Length x Width | mm | 933 x 439 |
| Height | mm | 978 |
| Wheelbase | mm | 308 |
| Turning circle | mm | 900 |
| Weight without batteries | kg | 40 |
| Weight with batteries | kg | 57 |
| Standard Tyres | 2 | Pneumatic |
| Optional Tyres | 2 | Super elastic non-marking wheels |
ML1 Bed Mover Dimensions
Features:
Wheels for Manual Transport
The electric hospital bed mover ML1 is provided with 2 pivoting wheels to carry it manually when not in use.
Foldable Clamp Arms
The clamp arms for the connection to the bed are foldable, to save more space with not in use
Patented Traction System
The innovatitve ML1 Traction system transfers the weight of the bed to the driving wheels through a patented spring mechanism.
Drive Unit Reversible & Portable
The driver controller of the electric bed mover ML1 can be moved from its housing and used by the operator from the other side of the bed.
Clamps with Adjustable Strength
The clamps are electronically controlled from the control panel through an amperomatric board.
Adjustable Upper Clamp
The upper clamp is adjustable in height and depth with two handles.
Customisable Clamps
On Request, it is possible to adapt custom clamps for different kinds of beds.
Superelastic non-marking Wheels
On Request, it is possible to adapt custom clamps for different kinds of beds.
LED Control Panel
ML1 is provided with control panel with LED lights to always get under control the speed, the battery charging level and when to recharge
Interchargeable Battery Packs
Lightweight and easy to replace battery packs, they allow to cover several work shifts.
Electric Actuators for Clamps
The movements of the clamps are controlled by electric actuators which are maintenance free.
Total Control on Your Fingertip!
The clamp group at first positions itself at the correct height, then closes to connect to the bed, and lastly slightly lifts the bed to activate the traction system. All by just pushing one button!
