Zallys M8 is a specific electric transporter for tube bundles, designed to transport tubes and bars up to 4 meters long and weighing up to 3,000 kg. Thanks to the front wheel drive of the motor wheel, it is extremely easy to handle even in narrow spaces, allowing the operator to bring the load closer to the production lines with agility. The Zallys M8 electric transporter for tube bundles is equipped as standard with 240 Ah AGM batteries which guarantee the use of the vehicle for at least two work shifts.
The particular modular structure of the machine allows, upon request, to extend the frame to carry pipes up to 6 meters and/or insert a customizable support surface to increase the capacity to 4,000 kg.
Like all Zallys vehicles, M8 is a high quality Made in Italy product, guaranteed and CE certified in compliance with current European regulations.
-
to transport loads up to 1,000 kg ;
-
versatile and compact;
-
with pneumatic wheels for indoor and outdoor use;
-
5-level travel speed adjustment;
-
wide range of standard or customizable platforms on request.
Ergonomic driving
The Zallys tillerhead was designed and created to make the operator’s use of the machine more ergonomic, guaranteeing the right comfort for prolonged use during the work shift. Its ergonomic design allows you to have everything at hand:
- ignition key;
- LED display showing the remaining battery charge and the set speed;
- button for selecting the 5 speeds;
- horn button;
- maintained action travel controls;
- anti-crushing safety button;
- two extra button slots for additional accessories.
La struttura è composta da materiali resistenti in caso di urti accidentali.
The right speed for every operation
For each level the speed of the machine increases by 20%, according to this curve:
- 1st level: Speed at 20%;
- 2nd level: Speed at 40%;
- 3rd level: Speed at 60%;
- 4th level: Speed at 80%;
- 5th level: Maximum speed;
N.B. The maximum speed of the machine is shown in the Technical Data section.
Autonomy for an entire working day
This model is equipped as standard with two 130Ah batteries, which guarantee the machine an autonomy of 8 working hours with continuous use.
The batteries are AGM sealed and therefore do not require maintenance.
High frequency external battery charger
The Zallys charger provides reliable and quality charging. Thanks to PFC (Power Factor Correction) technology, it improves battery performance during charging and prevents potentially harmful current peaks.
Furthermore, it is multi-voltage and adapts to the 110 or 220V electrical network and is equipped with “buffer” technology, essential for maintaining battery performance in the event of long periods of non-use.
Specifications
| Model name | M8 |
| Certification | CE |
| Loading capacity | 3-4000 kg |
| Maximum speed | 4 km/h |
| Weight (without batteries) | 339 kg |
| Length | 3,021 mm |
| Width | 671 mm |
| Height | 1,148 mm |
| Turning diameter | 2.8m |
